- Display: 7-inch touch screen
- Minimum sample size: 0.5μl - 2.0μl
- Path length: 0.05mm, 0.2mm, 1.0mm
- Light source: Xenon Flash Lamp
- Detector: 2048 Element Linear Silicon CCD Array
- Wavelength: 200 – 800nm (1nm steps)
- Absorbance range: 0.04 – 300 A (10mm equivalent)
- Absorbance precision: 003 A
- Lower limit of detection: dsDNA: 2ng/µl; BSA: 0.1mg/ml
- Upper limit of detection: dsDNA: 15,000ng/µl; BSA: 360mg/ml
- Detection time: < 6 seconds
- Communications ports: USB for data export
- Voltage Input: DC 24V, 2A
- Power: 25W
- Dimensions (WxDxH): 20.8 x 8.0 x 18.6 cm / 8.2 x 11.0 x 7.3 in.
- Weight: 3.6 kg / 7.9 lbs
Cuvette 0D600 detection
- Absorbance range: 0.0 - 4.0 A
- Absorbance stability: [0,3) ≤ 0.5%, [3,4) ≤ 2%
- Absorbance repeatability: [0,3) ≤ 0.5%, [3,4) ≤ 2%
- Absorbance precision: [0,2) ≤ 0.005 A, [2,3) ≤ 1%, [3,4) ≤ 2%
Fluorescence detection
- Excitation/Emission: 460 ± 20nm / 525-570nm
- Sensitivity: dsDNA: 0.5pg/µl
- Linearity: R² ≥ 0.995
- Repeatability: ≤ 1.5%
- Stability: ≤ 1.5%
