Erlab Chemtrap Chemical Storage Cabinet Filtration System (under bench)

Item#: CHEMTRAPV201V1

The Erlab Chemtrap Under-Bench Filtration System enhances lab safety by capturing and filtering hazardous vapors from chemical storage cabinets. Designed for under-bench installation, it features a sampling port for breakthrough testing, fan failure alarms, and an optional Securifilter alarm for solvent detection. Available with AS (organic vapors), BE (organic vapors and acids), or HP (HEPA H14 for powders) filtration, it operates with an airflow of >50 m³/h and consumes just 19W at 230V/50Hz. Built with anti-corrosion steel and an injected polypropylene filtration module, it measures 200mm W x 553mm D x 587mm H and includes a 1-meter flexible PVC pipe with adjustable fittings for easy setup.

Request a Quote
  • External Width (mm/in): 200mm/ 7 7/8 in
  • External Depth (mm/in): 553mm/ 22 ¾ in
  • External Height (mm/in): 587mm/ 23 1/8 in
  • Air Flow: > 50 m3 /h
  • Voltage/Frequency: 230 V / 50 Hz
  • Energy Consumption: 19 W
  • Flexible PVC pipe (meter / feet): 1 meter / 3 1/4’ ( ∅ 80 mm)
  • PVC fitting: ∅ 75-80-100 mm
  • Sampling port for filter breakthrough test
  • Fan failure alarm to monitor
  • Securifilter alarm for detection of solvent breakthrough
  • Filtration:
    • Types AS: For storage of organic vapors
    • Types BE: For storage of the organic vapors and acids mainly
    • Types HP: HEPA H14 for powders storing (Traps particles larger than 0.1 μm with 99.995% efficiency, according to the MPPS method set forth in the EN 1822-1 standard.)
  • Structure:
    • Metallic Parts: Anti-corrosion steel coated with 100% polyester.
    • Filtration module: Injected polypropylene
    • Pipe and fitting: PVC
  • Versions/Features:
    • Sampling Port
    • Sampling port + Fan Failure
    • Sampling port + Fan Failure + Securifilter
    • Sampling port + Securifilter
