Biofit Elite Series Cleanroom ESD Lab Chair | Standard Bench Height | 21” to 38” User Height | Blue

Item#: EEA-M-RK-T-AFP-XA-ISO3K-MBLU

The chair features a combination of ISO 3 / static control ESD package and is designed for use in 31” to 38” high desktop and bench-height applications. Features include easy pneumatic seat-height adjustments from 19” to 26”, an ergonomic seat with four-way contouring and internal seat board bumperguard measuring 18.5" wide x 17" deep x 3" thick, an upholstered backrest with lumbar support and plastic protective panel measuring 15.5” wide x 14.5” high. The seat and back are covered with Microcon blue vinyl upholstery to meet static control needs. The chair rests on a durable 25.6” diameter cast aluminum base with dual-wheel, non-marring polyurethane casters that resist movement when the chair is unoccupied and rated for ESD applications. Metal parts have chrome finish. Components packaged under laminar flow cleanroom hood.

Request a Quote

Supplier: BioFit

Height Compatibility: Standard Bench Height
Seat Covering Type: Upholstered
Seating Surface: Microcon
Seat Size: Medium
Back Size: Medium
Base: Wide Aluminum Base
ISO Cleanroom Standard: ISO 3
Static Control: Includes Static Control; Meets ANSI/ESD STM12.1 Standards
Finish Color: Chrome
Shipping Weight: 43
Product Dimensions: 26 x 26 x 38
Weight Capacity (lbs): 300
Seat-Height Adjustable Range: 19"-26"
Upholstery Type & Color: Microcon Grade B Blue
Seat Description: Ergonomic upholstered seat with four-way contouring and internal seat board bumperguard; measures 18.5" wide x 17" deep x 3" thick.
Back Description: Upholstered backrest with lumbar support and plastic protective panel; measures 15.5" wide x 14.5" high.
Control Description: Control allows function of the seat height activation and backrest adjustments by means of easily engaged levers which can be activated from the seated position. Seat tilt is fixed at 3.5° rearward while the backrest adjusts 8° forward and 13° rearward.
Base Description: Five-legged, solid cast aluminum base with caster-to-caster diameter of 25.6" and maximum width of 24.4". T-cross-section legs ensure cleanability, and endure test loads of 1.5-2x BIFMA strength requirements. Features standard 50mm tapered hub (1° 26' 16" (Morse) taper) with gauge line elevation of 113mm from the caster insert plane. The base is cast out of UNI EN 46100 aluminum with a robotically polished top surface to ensure quality and consistency.
Caster/Glide Description: Two inches in height, with dual soft-wheels. Casters resist movement when the seat is unoccupied. Plastic collar around caster stem to match base. Black tread indicates an ESD caster.
Recommended User Height: 31-38"
Seat Width (in): 18.5
Seat Depth (in): 17
Seat Cushion Thickness (in): 3
Back Width (in): 15.5
Back Height (in): 14.5
Footring Diameter (in): 22

Suitable for 31" to 38" Work Heights
Combination of ISO 3 / static control ESD package
Ergonomic seat with four-way contouring
Internal seat board bumper guard measuring 18.5" wide x 17" deep x 3" thick
Upholstered backrest with lumbar support and plastic protective panel measuring 15.5” wide x 14.5” high
Pneumatic seat-height adjustment range of 19” to 26”
Upholstered in Microcon blue vinyl upholstery to meet static control needs
Chair rests on a durable 25.6” diameter cast aluminum base
Has dual-wheel, non-marring polyurethane casters that resist movement when the chair is unoccupied
Metal parts have chrome finish
Components packaged under laminar flow cleanroom hood.
Complies with product safety and performance standards guidelines as established by: ANSI, BIFMA & is LEED^® compliant
Meets CAL 117 fire retardant standards
13-year warranty with lifetime warranty on pneumatics
