BINDER FD115 Avantgarde.Line Standard Series FD Drying/Heating Chambers with Forced Convection, 120V | 4.1 cu.ft.
Item#: 9010-0306The BINDER FD115 Avantgarde.Line Drying and Heating Chamber is a versatile forced-convection oven designed for precise drying, heating, conditioning, and thermal testing in laboratory environments. Its 4.1 cu. ft. chamber, rapid heat-up performance, and temperature range up to 300°C deliver excellent temperature uniformity and consistent, reproducible results across a wide range of applications. Featuring enhanced airflow performance, energy-efficient operation, and support for up to five shelves, the FD115 provides reliable flexibility for research, quality control, and routine laboratory workflows.
$3,642.00 $3,459.90
Performance Data Temperature
- Heating-up time to 150 °C [min]- 18
- Recovery time after 30 seconds door open at 150 °C [min]- 4
- Temperature fluctuation at 150 °C [± K]- 0.3
- Temperature range +10 °C above ambient temperature to [°C]- 300
- Temperature variation at 150 °C [± K]- 1.7
Air change data
- Air change (approx.) at 100 °C [x/h]- 32
Electrical data
- Nominal power [kW]- 1.4
- Phase (Nominal voltage)- 1~
- Power frequency [Hz]- 60
- Rated Voltage [V]- 120
- Unit fuse [A]- 12.5
Doors
- Unit doors- 1
Housing dimensions not incl. fittings and connections
- Depth net [in]- 23.84
- Height net [in]- 28.96
- Width net [in]- 27.97
Internal Dimensions
- Depth [in]- 15.17
- Height [in]- 21.67
- Width [in]- 21.67
Measures
- Interior volume [cu.ft.]- 4.1
- Load per rack [lbs]- 66
- Net weight of the unit (empty) [lbs]- 126
- Permitted load [lbs]- 331
- Wall clearance back [in]- 6.3
- Wall clearance sidewise [in]- 3.94
Environment-specific data
- Energy consumption at 150 °C [Wh/h]- 340
- Sound-pressure level [dB(A)]- 43
Fixtures
- Number of shelves (std./max.)- 2/5
- Temperature range: ambient temperature plus 10 °C to 300 °C
- Up to 30% lower energy consumption compared to conventional units on the market
- High temperature accuracy thanks to APT.line™ technology
- Forced convection
- Controller with LCD display
- Electromechanical control of the exhaust air flap
- 2 chrome-plated racks
- Stackable
- Class 2 integrated independent adjustable temperature safety device (DIN 12880) with visual alarm
- Ergonomic handle design
- USB port for recording data
- Warranty: 2 years parts & labor
