BINDER FED260 Avantgarde.Line Standard Series FED Drying/Heating Chambers w/ Forced Convection & Enhanced Timer Functions, 240V | 9.1 cu.ft.
Item#: 9010-0300The BINDER FED260 Avantgarde.Line Drying and Heating Chamber is a high-capacity forced-convection oven engineered for precise drying, heating, conditioning, and thermal testing applications. Its spacious 9.1 cu. ft. chamber, rapid heat-up performance, and temperature range up to 300°C provide excellent temperature uniformity and consistent, reproducible results across larger sample loads. Designed for demanding laboratory and industrial workflows, the FED260 features enhanced timer functions, support for up to eight shelves, and a high load capacity for maximum flexibility and productivity.
$6,976.00 $6,627.20
Performance Data Temperature
- Heating-up time to 150 °C [min]- 19
- Recovery time after 30 seconds door open at 150 °C [min]- 5
- Temperature fluctuation at 150 °C [± K]- 0.4
- Temperature range +10 °C above ambient temperature to [°C]- 300
- Temperature variation at 150 °C [± K]- 1.6
Air change data
- Air change (approx.) at 100 °C [x/h]- 9
Electrical data
- Nominal power [kW]- 2.5
- Phase (Nominal voltage)- 1~
- Power frequency [Hz]- 60
- Rated Voltage [V]- 240
- Unit fuse [A]- 16
Doors
- Unit doors- 1
Housing dimensions not incl. fittings and connections
- Depth net [in]- 29.94
- Height net [in]- 38.02
- Width net [in]- 31.91
Internal Dimensions
- Depth [in]- 20.29
- Height [in]- 30.73
- Width [in]- 25.61
Measures
- Interior volume [cu.ft.]- 9.1
- Load per rack [lbs]- 88
- Net weight of the unit (empty) [lbs]- 185
- Permitted load [lbs]- 595
- Wall clearance back [in]- 6.3
- Wall clearance sidewise [in]- 3.94
Environment-specific data
- Energy consumption at 150 °C [Wh/h]- 410
- Sound-pressure level [dB(A)]- 43
Fixtures
- Number of shelves (std./max.)- 2/8
- Temperature range: ambient temperature plus 10 °C to 300 °C
- Up to 30% lower energy consumption compared to conventional units on the market
- High temperature accuracy thanks to APT.line™ technology
- Adjustable fan speed
- Controller with LCD display and enhanced time functions
- Electromechanical control of the exhaust air flap
- 2 chrome-plated racks
- Class 2 integrated independent adjustable temperature safety device (DIN 12880) with visual alarm
- Ergonomic handle design
- Ethernet interface
- USB port for recording data
- Warranty: 2 years parts & labor
