Memmert HCP105 Humidity Chamber | 3.78 cu. ft.
Item#: HCP105115VHCP 105 Memmert climate chambers guarantee the perfect atmosphere for climate and temperature tests. High-precision control technology creates controlled and physiologically ideal surroundings for the perfect environment simulation in building physics, electronics, biology, zoology and botany.
$15,134.00
- Product Specifications
- Product Features
- Literature & Manuals
- Product Videos
- Product Accessories
- Request a Proposal
- Volume: 3.78 cu. ft. | 107 L
- Interior Dimensions W x H x D in (mm): 22" x 18.9" x 15.7" (558.8 x 480.06 x 398.79 mm)
- Exterior Dimensions W x H x D in (mm): 28.3" x 33.5" x 23.2" (718.82 x 850.9 x 589.28 mm)
- Housing: corrosion resistant stainless steel
- Max. number of internals: 6
- Max. loading of chamber: 198 lbs (89.81 kgs)
- Max. loading per internal: 44.09 lbs (14.97 kgs)
- Electrical data: 115 Volts: 50/60 Hz /approx. 15 A (230V model available, please inquire)
Temperature Specs:
- Setting temperature range: +18 to 90°C
- Working temperature range without humidity: 6°C up to +90°C
- Setting accuracy temperature: 0.1°C
- Temperature sensor: 2 Pt100 sensors Class A in 4-wire-circuit, mutually monitoring and taking over the performance at the same temperature value
Humidity Specs:
- Setting range humidity:20 to 95 % rh and rh-Off
- Setting accuracy humidity: 0.5% rh
- Humidity: humidity supply with distilled water from external tank by self-priming pump
- Stainless Steel Exterior: Scratch resistant, hygienic and durable.
- Warranty: A limited 3 year warranty is included with the option to purchase an extra year.
- ControlCOCKPIT: TwinDISPLAY. Adaptive multi-functional digital PID-microprocessor controller with 2 high-definition TFT-colour displays.
- Language Setting: German, English, Spanish, French, Polish, Czech, Hungarian
- Adjustable Parameters: Temperature (Celsius or Fahrenheit), relative humidity, program time, time zones, summertime/wintertime
- Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days
- Function SetpointWAIT: The process time does not start until the set temperature is reached
- Calibration: Three freely selectable temperature values
- Temperature control: mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 10°C above nominal temperature
- AutoSAFETY: additionally integrated over- and under temperature protection “ASF”, automatically following the setpoint value at a preset tolerance range, alarm in case of over- or under temperature, heating is switched off in case of overtemperature, the compressor in case of under temperature
- Alarm: with visual and acoustic alarm in case of over-/under temperature and under humidity, open door and empty water tank
- Temperature control: over- and under temperature monitor TWW, protection class 3.3 or adjustable temperature limiter TWB, protection class 2, adjustable at the controller
- Autodiagnostic system: integral fault diagnostics for temperature and humidity control
