Caron Model RC Laboratory Automation & Robotic Enclosure Systems
Item#: RC180PThe RC Class II Enclosures are equipped with pre-filtration which eliminates particles of 5.0μm or larger to an efficiency of 92% as per BS EN ISO 779 standards.
|
Model |
External Dimensions mm (WxDxH) | Internal Dimensions mm (WxDxH) |
|
RC180P |
1800 x 1400 x 2570 |
1720 x 1200 x 1063 |
|
RC220Q |
2200 x 1400 x 2570 |
2120 x 1200 x 1063 |
|
RC260R |
2600 x 1400 x 2570 |
2520 x 1200 x 1063 |
| RC300S | 3200 x 1400 x 2570 |
2920 x 1200 x 1063 |
- Sound level: <65dBA
- Lighting: 2 x 18W sealed fluorescent amps >480lux
- 110V, AC, 60Hz, 20Amp, 1Ø
- Offers in-process operator and product protection with access through 325mm high sliding windows.
- Comes with a programmable control system that displays the status of the enclosure and controls the airflow balance, with an hour counter.
- Exterior mounted display shows the status of the enclosure
- Great visibility of the enclosed system.
- Audible and visual alarm signals low airflow and door open warning.
- Display/lighting showing status of enclosed robotic system (with option for status lighting above control display position)
Additional Features
- Computer shelf on a flexible arm
- Additional electrical sockets to fit the robotic system
- Integrated robot system safety switches
- Under-bench storage, shelving, and cupboards to fit
- Universal control panel with linked UV lighting and timed on/off control
- Ventilated waste tips and plate containers
