Jeio Tech BS2-30 Reciprocal Shaking Heating Bath | 55L
Item#: AAH44305KJeio Tech BS2-30 reciprocal shaking heating bath is a 55 L laboratory shaking bath designed for precise incubation of DNA, tissue cultures, and heat-sensitive samples in research and clinical laboratories. The system combines reciprocal shaking motion with PID temperature control to deliver stable temperatures from ambient +5°C to 100°C and uniform heat distribution during demanding incubation workflows. A touchscreen color display, programmable timer functions, USB connectivity, and optional mobile monitoring support convenient operation and real-time process monitoring. Safety features including low water level alarms, heater shutdown protection, over-current protection, and transparent condensation-resistant covers help ensure reliable and secure laboratory performance.
$4,717.00 $4,340.00
- Bath volume (L / cu ft): 55 / 1.9
- Temperature
- Working temp. range (℃ / ℉): Amb. +5 to 100 / Amb. +9 to 212
- Temp. stability at 50℃ (±℃ / ℉): 0.1 / 0.18
- Shaking system
- Motion type: Reciprocal
- Frequency (rpm): 30 to 200
- Stroke length (mm / inch): 30 / 1.18
- Dimension
- Bath opening / depth (W x L x D) (mm / inch): 565 x 319 x 192 / 22.2×12.6 x 7.6
- Exterior (W x L x H) (mm / inch): 882 x 467 x 426 / 34.7 x 18.4 x 16.8
- Net weight (kg / lbs): 38 / 84
- Bath opening / depth (W x L x D) (mm / inch): 565 x 319 x 192 / 22.2×12.6 x 7.6
- Electrical requirements (230V, 60Hz, A): 8.9
Performance
- Temperature range from ambient +5°C to 100°C (amb. +9℉ to 212℉).
- Precise rpm(Max 200rpm) and temperature(Max 100℃) control with accuracy.
- Excellent temperature distribution by shaking motion. (50℃ ±0.1℃)
- Better performance with 3-points temperature calibration and 1-point shaking calibration.
- Optimal PID control for the Bath.
- Bath structure for a smooth water circulation flow.
- Extended height for larger sample volumes. (maximum 2.8L of flasks)
Convenience
- Automatic On/Off timer. (up to a maximum of 999 hours and 59 minutes)
- Easy operation with a touch color display.
- Drain port of better accessibility located on the side.
- USB port to connect to PC for recording and monitoring.
- Transparent gable roof-shape cover prevents condensed water from falling onto specimen.
- Corrosion resistance spring wire rack (1ea) is provided. (Standard)
- Real-time temperature and rpm control via mobile monitoring system. (Option)
Safety
- Audio and visual alarms and heater shutdown in case of water shortage.
- Alarm for temperature and rpm discrepancies or abnormal condition of temperature sensor.
- Over-current and short circuit protection of device.
