Labconco Protector Protector XL I-S Benchtop Laboratory Fume Hoods

Item#: PROTECTORXLl-S

Protector XL I-S Benchtop Laboratory fume hoods are general chemistry hoods that offer superior design flexibility. They are available in widths from 3 to 8 feet and two depths to meet a variety of installation and application requirements.

Designed for use with Intelli-Sense Multi-Speed Blowers, Protector XL I-S Benchtop Hoods feature integrated sash position blower controls. As the sash is raised or lowered, sensors alert the blower to change speeds to maintain a safe face velocity. That face velocity is displayed on the factory-installed Guardian™ Digital Airflow Monitor for users’ peace of mind.

These hoods are suitable for providing personal protection needed for general chemistry applications involving fumes and vapors. They meet the SEFA-1 standard of a low velocity, high performance hood and may be safely operated as low as 60 fpm.

Supplier: Labconco

Exceed SEFA 1 standards for high performance fume hood
By-pass design with upper by-pass block to reduce airflow (CFM)
Exclusive Air Foil®
- With maximum containment airflow openings
- Cord-keeping slots on either side for safety
Pre-wired LED lighting
- Rated for up to 50,000 hours
- Vapor-proof design
- ADA-compliant light and blower switches
Baffle(s) with flame spread index less than 25 per ASTM E84
Built-in Digital Guardian Airflow monitor for safe operation
Tempered safety glass sash
- With chain and sprocket
- Vertical-rising design
- Powder-coated aluminum handles have maximum containment airflow openings
37.5" high sightline from work surface to header panel
12.8" ID exhaust connection(s)
Removable front and side panels
Glacier white powder-coated steel exterior
Zone-optimizing baffle with tapered slots*
Chemical-resistant, fiberglass-reinforced, composite panel liner
Powder-coated stainless steel connections

4 ft. Hood Airflow and Static Pressure

Blower Speed	Sash (inches)	Face Velocity (fpm)	Airflow Volume (CFM)	XL SP (in. of H2O)
LOW	0”-4”	190	200	0.02
MEDIUM	4”-18”	100	440	0.10
HIGH	18”-28”	100	705	0.26
LOW	0”-4”	190	200	0.02
MEDIUM	4”-18”	80	350	0.06
HIGH	18”-28”	80	565	0.17
LOW	0”-4”	190	200	0.02
MEDIUM	4”-18”	60	265	0.04
HIGH	18”-28”	60	425	0.09

5 ft. Hood Airflow and Static Pressure

Blower Speed	Sash (inches)	Face Velocity (fpm)	Airflow Volume (CFM)	XL SP (in. of H2O)
LOW	0”-4”	190	260	0.03
MEDIUM	4”-18”	100	580	0.12
HIGH	18”-28”	100	930	0.32
LOW	0”-4”	190	260	0.03
MEDIUM	4”-18”	80	465	0.08
HIGH	18”-28”	80	745	0.20
LOW	0”-4”	190	260	0.03
MEDIUM	4”-18”	60	350	0.05
HIGH	18”-28”	60	560	0.12

6 ft. Hood Airflow and Static Pressure

Blower Speed	Sash (inches)	Face Velocity (fpm)	Airflow Volume (CFM)	XL SP (in. of H2O)
LOW	0”-4”	190	320	0.04
MEDIUM	4”-18”	100	720	0.17
HIGH	18”-28”	100	1150	0.44
LOW	0”-4”	190	320	0.04
MEDIUM	4”-18”	80	575	0.11
HIGH	18”-28”	80	920	0.27
LOW	0”-4”	190	320	0.04
MEDIUM	4”-18”	60	430	0.07
HIGH	18”-28”	60	690	0.16

8 ft. Hood Airflow and Static Pressure

Blower Speed	Sash (inches)	Face Velocity (fpm)	Airflow Volume (CFM)	Premier SP (in. of H2O)
LOW	0”-4”	190	440	0.02
MEDIUM	4”-18”	100	1000	0.12
HIGH	18”-28”	80	1280	0.19
LOW	0”-4”	190	440	0.02
MEDIUM	4”-18”	80	800	0.08
HIGH	18”-28”	80	1280	0.19
LOW	0”-4”	190	440	0.02
MEDIUM	4”-18”	60	600	0.04
HIGH	18”-28”	60	960	0.11

By-pass airflow design
Eco-Foil™ Air Foil with aerodynamic Clean-Sweep™ airflow openings
Cord-Keeper™ Slots on left and right side of air foil
Factory-installed Intelli-Sense Blower control box
Factory-installed sash position activated blower speed switches
Factory-installed Guardian™ Digital Airflow Monitor
Glacier white powder-coated steel exterior
Chemical-resistant, fiberglass-reinforced, composite panel liner and baffle
Opti-Zone™ Baffle with flame spread index less than 25 per ASTM E84. Baffle is removable for cleaning
Tempered safety glass vertical-rising sash(es) with cable and pulley(s) and powder-coated aluminum sash handle(s)
37.5" (95.3 cm) high sightline from the work surface and header panel
Removable front and side panels, and front and interior service access panels for access to plumbing and electrical wiring
Pre-wired LED lighting with vapor-proof design and ADA-compliant light and blower switches. Lighting rated to 50,000 hours.
Powder-coated stainless steel, 12.8" (32.5 cm) ID exhaust connection(s)

Fixtured Models May Feature

Two pre-plumbed service fixtures with forged brass valves, lower right side with brass tubing for gas and lower left side with copper tubing for cold water. Components for converting either or both fixtures to air and vacuum are provided. Inlet tubing is not provided.
One pre-wired GFCI electrical duplex receptacle on lower right side and, on 8' models only, one additional pre-wired GFCI electrical duplex receptacle on lower left side

Required Accessories (Not Included)
