Leica DM4 B Automated Upright Microscope System for Life Science and Clinical Applications

Stand

• Power supply: Integrated within stand
• Display: Information display
• Interfaces: 1 x USB 2.0, 1 x I2C

Operation

• Focus:
  • Mechanical
  • 2-ratio gearbox (coarse/fine)
• Objective turret:
  • Absolute coded
  • 6x M25 thread
  • 7x M25 thread (optional)
• Stage:
  • Mechanical
  • Ceramic-coated
  • Y-drive with belt
  • Removable stage drive with adjustable torque
  • 110° swivel
  • left-handed version optionally available
• Controls: 6 programmable function buttons
• Specimen Overview Tool: No

TL Axis

• Illumination: LED
• Automation:
  • Light manager: automatic Köhler light management sets the best values for aperture, field diaphragm, and light intensity
  • Contrast manager: switch from one contrast method to another with one push of a button
• Contrast Method: BF, PH, DF, POL, DIC (semi-automated)

Flou-Axis

• Motorized filter cube turret: 5X
• Illumination:
  • Leica EL6000
  • Leica SFL100/4000
  • 3rd Party
• Automation:
  • Fluorescence Intensity Manager (FIM): regulation of the excitation light to effectively protect the specimen from photo bleaching
  • Contrast manager: switch from one contrast method to another with one push of a button
  • Round and square illuminated field diaphragms for ocular and camera observation (motorized)

Condensers

• Automation:
  • condenser head, motorized
  • 7x condenser disk, motorized (optional)
  • polarizer, motorized (optional)
