Stand
- Power supply: Within electronics box CTR6 or CTR6 LED
- Display: Leica SmartTouch with information and controls
- Interfaces: 2 x USB 2.0, 2 x I2C
Operation
- Focus:
- Motorized or mechanical
- 5 electronic ratios
- Includes parfocal function
- Switch between coarse and fine mode
- Memory locations for two z-positions
- Objective turret:
- Motorized or coded
- Includes dry & immersion mode
- 7x M25 thread
- Stage:
- Mechanical
- Ceramic-coated
- Y-drive with belt
- Removable stage drive with adjustable torque
- 110° swivel
- Memory location for up to 5 stage positions
- Motorized (optional) with stepper motor switch between fast & precision mode
- left-handed version optionally available
- Controls:
- 6 programmable function buttons
- SmartMove controls for z (focus) movement and x,y (stage) movement, 4 programmable function buttons
- Leica STP8000 controls for z (coarse and fine focus) and x,y (stage) movement, 11 programmable function buttons, touchpanel with information and control panels
- Specimen Overview Tool: Yes
TL Axis
- Illumination: Either 12 V 100 W halogen lamp or LED
- Automation:
- Light manager: automatic Köhler light management sets the best values for aperture, field diaphragm, and light intensity
- Contrast manager: switch from one contrast method to another with one push of a button
- Constant Color Intensity Control: maintains a constant color temperature (3200 K) (for Halogen versions only)
- Contrast Method: BF, PH, DF, POL, DIC (fully automated)
Flou-Axis
- Motorized filter cube turret: 5X & 8X
- Illumination:
- Leica EL6000
- Leica SFL4000/7000
- 3rd Party
- Automation:
- Fluorescence Intensity Manager (FIM): regulation of the excitation light to effectively protect the specimen from photo bleaching
- Contrast manager: switch from one contrast method to another with one push of a button
- Round and square illuminated field diaphragms for ocular and camera observation (motorized)
- Excitation Manager: balances fluorescence when viewing multiple probes simultaneously (optional)
Condensers
- Automation:
- condenser head, motorized
- 7x condenser disk, motorized (optional)
- polarizer, motorized (optional)
