Large Mouse Suspended Shelf Rack Static Caging Systems

• Part Number: SPCR30-86-PC-WB
  • Dimensions W” x D” x H”: 70.75×21.75×69.1
  • Dimensions W x D x H: 179.7×55.2×175.5 cm
  • Cages: 30
  • Per Shelf: 5
  • Rodent Count: 270
  • Footprint Sq Ft: 10.7
  • Animals Sq Ft: 5.6
  • Gauge: 18
• Part Number: SPCR36-86-PC-WB
  • Dimensions W” x D” x H”: 70.75×21.75×80.6
  • Dimensions W x D x H: 179.7×55.2×204.7 cm
  • Cages: 36
  • Per Shelf: 5
  • Rodent Count: 324
  • Footprint Sq Ft: 10.7
  • Animals Sq Ft: 6.7
  • Gauge: 18
• Part Number: SPCR30-86-UD-E
  • Dimensions W” x D” x H”: 69.5×21.75×70.75
  • Dimensions W x D x H: 179.7×55.2×176.5 cm
  • Cages: 30
  • Per Shelf: 5
  • Rodent Count: 270
  • Footprint Sq Ft: 10.5
  • Animals Sq Ft: 5.5
  • Gauge: 18

IMPORTANT: INITIAL CLEANING
All components of the Alternative Design stainless steel product must be cleaned, sanitized and sterilized, where applicable, prior to being put into service. This unit is made primarily of 304 stainless steel. Use care when cleaning to prevent corrosion that can shorten useful life. Cleaning solutions which contain high levels of chlorine are not recommended for stainless steel parts.

Caster Maintenance
Caster used on this equipment was chosen for its suitability in applications where frequent washdowns are necessary. It is also well suited for applications exposed to heat, cleaning agents, steam, caustic solutions or other corrosive agents, which could cause rust and contamination. After washing and/or autoclaving, check casters for proper operation. Check the axle nut to ensure it is still tight (125 inch/pound is recommended). If the axle and/or swivel bearing has to be lubricated, use a high temp grease.
