Lab Companion IB-25G Versatile Air-Jacketed Natural Convection Incubator (151 L/5.3 Cu. ft.)
Item#: AAH21186U$3,717.00 $3,531.15
- Chamber volume (L / cu ft): 151 / 5.3
- Temperature-
- Range (℃ / ℉): Amb. +5 to 70 / Amb. +9 to 158
- Fluctuation at 37℃ (±℃ / ℉): 0.2 / 0.36
- Variation at 37℃ (±℃ / ℉): 0.6 / 1.08
- Dimensions-
- Exterior (W×D×H): 805×655×885 mm/ 32"×26"×35"
- Interior (W×D×H): 610×460×540mm/ 24"×18"×21.3"
- No. of wire shelf (standard / max.): 2 / 11
- Net weight (Kg / lbs): 62 / 136
- Electrical requirements (120V, 50 / 60Hz): 6.4A (230V model available, use AAH21182K)
Performance
- Temperature range from ambient +5°C to 70°C.
- Microprocessor PID control / Temperature calibration / Automatic tuning.
- Vibration-free design ideal for yeast cultivation.
- Air-jacked natural convection is beneficial for Uniform temperature distribution and minimal sample contamination caused by external air intrusion. - Durable incoloy heating element with radiator fans for efficient heat dissipation.
Convenience
- Intuitive control panel with bright LED display. (0.1℃resolution)
- Dual wait on/off timer modes. (1 min. to 99 hr. 59 min.)
- Convenient preset function for 3 most commonly used temperature settings.
- Convenient sample monitoring without affecting chamber temperature via the inner tempered-glass door.
- Corrosion-resistant stainless steel interior with rounded corners for easy cleaning and optimal airflow.
- Fully insulated dual-wall door with magnetic rubber gasket.
- Built-in cable port to use other instruments inside the chamber. (diameter: 38mm)
- RS-232 interface for external control and data collection.
- Stackable up to 2 units using the optional stacking kit. (optional)
Safety
- Automatic run after power interruption.
- Keypad lock function prevents accidental changes during operation.
- Over-temperature and over-current protection.
- Audible and visible open door alarms.
